Fiberlogy PET-G ESD/antistatic black 0,5 kg
Fiberlogy PET-G ESD/antistatic black 0,5 kg
Ensure the security of your electronic devices by protecting them with Fiberlogy PET-G ESD filament. Due to its high energy dissipation capability, it protects integrated circuits and other sensitive components against the effects of electronic discharges. No more need to worry about the costs of repairs and downtime. More
Manufacturer: FiberlogyProduct code: 428 Shipping and Payment
Ensure the security of your electronic devices by protecting them with Fiberlogy PET-G ESD filament. Due to its high energy dissipation capability, it protects integrated circuits and other sensitive components against the effects of electronic discharges. No more need to worry about the costs of repairs and downtime. More
Manufacturer: FiberlogyProduct code: 428 Shipping and Payment
The destructive nature of electrostatic discharge leads to the generation of high costs related to the maintenance, repair and replacement of vulnerable components that companies have to bear, especially those which produce and use electronics in conditions that are conducive to the occurrence of the ESD effect. The task of ESD from Fiberlogy is to eliminate this threat. Therefore, the ESD filament will come in handy when printing housings for integrated circuits, sensors, connectors, measuring devices.
Properties:
- high resistance to electrostatic discharge and chemicals
- high impact strength
- resistance to high temperatures and scratching
- possibility of mechanical and chemical processing
Applications
- Electronics: housings, covers, cases, screens products equipped with diodes, connectors
- Tools or their parts: tools for working with electronics, tools for making electronic components
- Parts and transmission tools: machine components, elements of equipment for employees and manufacturing plants
Recommended print settings by manufacturer
The following parameters are only suggested print settings for this material. To ensure the best print quality, it is necessary to choose the appropriate settings for a specific printer and printing conditions.
- Nozzle Temperature: 230-250°C
- Bed Temperature: 85°C
- Closed chamber: recommended
- Fan: 0-10%
- Flowrate: 95-105%
- Printing Speed: 35-60 mm/s
- Surface: glass, masking tape
- Retraction (direct): 2-3 mm
- Retraction (bowden): 4-6 mm
- Retraction Speed: 20-45 mm/s
- Drying conditions: 60°C / 4h
Notes
Due to the strong adhesion to the bed, it is not recommended to print directly on its surface or on glass. This can lead to damage. We recommend using a masking tape.
Due to the content of carbon nanoparticles, the minimum recommended nozzle diameter is 0.5 mm.
Technical information
- Material: polyethylene terephthalate glycol (PET-G)
- Diameter: 1,75 mm
- Weight: 500 g
- Diameter tolerance: +/- 0.02 mm
- Tolerance of roundness: +/- 0.01 mm
- Heat resistance: 75 °C
- Glass transition temperature: 85 °C
Package
wound on spool, vacuum-packed in a plastic bag, placed in a cardboard box
| Color |  |
|---|---|
| Manufacturer | Fiberlogy |
| Filament weight | 0.5 kg |
| Filament material | PET-G |
| Compatible with AMS | Yes |
| Compatible with AMS Lite | Yes |
| Filament diameter | 1,75 mm |
| Heated bed temperature | 85 °C |
| Hotend temperature | 230 - 250 °C |
| Diameter tolerance | ± 0,02 mm |
| Spool diameter | 200 mm |
| Material surface | Light gloss |
| Spool width | 86 mm |
| Spool hole diameter | 52 mm |
| Closed chamber | Recommended |
| Roundness tolerance | ± 0,01 mm |
| Difficulty of printing | Advanced |
| Drying conditions | 60 °C / 4h |
| Glass transition temperature | 85 °C |
| Heat Distortion Temp | 75 °C |
| Filament characteristics | Antistatic(ESD) |
