Fiberlogy Fiberflex 40D black 0,85 kg
Fiberlogy Fiberflex 40D black 0,85 kg
Pick up the pace
Fast and precise. Yes, it’s possible. FIBERFLEX 40D is the best proof of this. With this flexible material with Shore hardness of D40 you can print at the speed of 45mm/s without worrying about the quality of the print. What’s more, thanks to FIBERFLEX 40D you will discover that printing with flexible filaments doesn’t have to be difficult. Feeding it to the extruder will be extremely easy and the printed layers will stick together well. More
Manufacturer: FiberlogyProduct code: 171 Shipping and Payment
Pick up the pace
Fast and precise. Yes, it’s possible. FIBERFLEX 40D is the best proof of this. With this flexible material with Shore hardness of D40 you can print at the speed of 45mm/s without worrying about the quality of the print. What’s more, thanks to FIBERFLEX 40D you will discover that printing with flexible filaments doesn’t have to be difficult. Feeding it to the extruder will be extremely easy and the printed layers will stick together well. More
Manufacturer: FiberlogyProduct code: 171 Shipping and Payment
Your prints will have such properties as: high impact resistance, high temperature resistance, chemical and abrasion resistance. Because of that FIBERFLEX 40D can be used for both amateur and professional applications.
Properties:
- 40D Shore hardness
- high impact resistance in low temperatures
- very good thermal, chemical and abrasion resistance
Applications
- RUBBER ELEMENTS OF MACHINES: gaskets, elements that are frequently bent
- GADGETS OR THEIR ELEMENTS: phone sleeves and cases, watch-, pulse counter-, pedometer straps
- LINKING ELEMENTS: flexible hinges
- TOYS OR THEIR ELEMENTS: tires, rubber figures
- JEWELLERY: bands, bracelets
Recommended print settings by manufacturer
The following parameters are only suggested print settings for this material. To ensure the best print quality, it is necessary to choose the appropriate settings for a specific printer and printing conditions.
- Nozzle Temperature: 200-220°C
- Bed Temperature: 50-70°C
- Closed chamber: not required
- Fan: 50-75%
- Flowrate: 105-110%
- Printing Speed: < 45 mm/s
- Surface: glass, masking tape
- Retraction (direct): 1-2 mm
- Retraction Speed: 10-30 mm/s
Notes
To remove the print easier, it is recommended to heat the bed to 110°C
Technical information
- Material: Thermoplastic Copolyester Elastomer > 96%, Aditives ≤ 4%
- Diameter: 1,75 mm
- Diameter tolerance: +/- 0.05 mm
- Tolerance of roundness: +/- 0.03 mm
- Weight: 850 g
- Heat distortion temperature: 70°C
- Melting point: 160°C
- Shore D hardness: 40
- Shore A hardness: 91
Package
wound on spool, vacuum-packed in a plastic bag, placed in a cardboard box
| Color |  |
|---|---|
| Manufacturer | Fiberlogy |
| Filament weight | 0,85 Kg |
| Filament material | TPE |
| Compatible with AMS | Yes |
| Compatible with AMS Lite | Yes |
| Filament diameter | 1,75 mm |
| Heated bed temperature | 50 - 70 °C |
| Hotend temperature | 200 - 220 °C |
| Diameter tolerance | ± 0,05 mm |
| Spool diameter | 200 mm |
| Material surface | Mat |
| Spool width | 86 mm |
| Spool hole diameter | 52 mm |
| Closed chamber | Not required |
| Hardness | 40D |
| Roundness tolerance | ± 0,03 mm |
| Difficulty of printing | Advanced |
| Heat Distortion Temp | 70 °C |
| Melting temperature | 160 °C |
