Spectrum ASA 275 bloody red
Spectrum ASA 275 bloody red
Professional grade material showing excellent resistance to external exposure, changing weather conditions & UV radiation.
Vicat softening temperature – 94°C
High speed 3D printing (up to 200mm/s)
Ease of printing comparable to classic PLA More
Manufacturer: SpectrumProduct code: 104 Shipping and Payment
Professional grade material showing excellent resistance to external exposure, changing weather conditions & UV radiation.
Vicat softening temperature – 94°C
High speed 3D printing (up to 200mm/s)
Ease of printing comparable to classic PLA More
Manufacturer: SpectrumProduct code: 104 Shipping and Payment
UV and thermal resistance
Filament Spectrum ASA 275 is a professional material, designed for desktop 3D printers. The composition of Spectrum ASA 275 has been specially modified to make the material more flexible, improve flow parameters, reduce shrinkage, and increase adhesion between layers.
One of the main advantages of the modification of ASA 275 material is simplification of printing parameters. Spectrum ASA 275 technical material can be printed with nearly the same ease as Premium PLA. This allows the production of large models without the risk of deformation after cooling, but also obtaining relatively high printing speeds.
ASA 275 is a material resistant to UV radiation and other weather conditions. ASA 275 can be used for printing prototypes, functional production tools, but also elements that must withstand changing weather conditions, and even everyday use items.
Material characteristics
- excellent resistance to external exposure and changing weather conditions
- good thermal resistance HDT – 85°C
- Vicat softening temperature – 94°C
- resistance to UV radiation,
- perfect interlayer adhesion,
- ability to print on desktop printers without a heated chamber
- high speed printing (up to 200mm/s)
- glossy print surface,
- ease of printing comparable to classic PLA
- ASA 275 material is not suitable for printing mechanically stressed parts e.g. 3D printers like Voron (high material creep)
Applications
- functional prototypes
- tooling
- production tools
- end-use parts
- custom components
Manufacturer print parameters recommendation
- Nozzle temperature: 200-240°C
- Bed temperature: 40-60°C
- Heated chamber: Recommended for larger prints
- Active cooling fan: up to 100%
- Print speed: 40-200 mm/s
- Flowrate: 100-105%
- Retraction - direct: 1-3 mm
- Retraction - bowden: 4-6 mm
- Retraction speed: 25-45 mm/s
Technical data
- Material: ASA
- Diameter: 1.75 mm
- Weight: 1000 g
- Diameter tolerance: +/- 0.05 mm
- Density: 1.08 g/cm3
- Thermal resistance: up to 94 °C
- Verify your spool: YES (course of diameter – online graph - on the entire length of the spool, mean diameter, ovality, standard deviation individually for each manufactured spool)
Storage and shelf life
Filament should be stored in a dry room at room temperature. Recommended storage temperature is ca. 18-25°C (64.4 -77.0°F). Keep out of moisture, sunlight and direct heat. When stored properly, product has a shelf life of 24 months.
Color | |
---|---|
Manufacturer | Spectrum |
Filament weight | 1 Kg |
Filament material | ASA |
Filament diameter | 1,75 mm |
Heated bed temperature | 40 - 60 °C |
Hotend temperature | 200 - 240 °C |
Diameter tolerance | ± 0,05 mm |
Softening temperature | 94 °C |
Closed chamber | Recommended |
Difficulty of printing | Beginner |
Drying conditions | 80 °C / 12h |
Heat Distortion Temp | 84 °C |
