BIGTREETECH EBB SB2209 USB is a modern and powerful board designed for 3D printing enthusiasts and professionals who use Voron printers with the Stealthburner toolhead. This board combines high performance and quiet operation, making it ideal for users seeking reliable and efficient solutions for their projects.

The main benefit of this board is its easy installation thanks to the USB interface and powerful TMC2209 driver, which ensures quiet operation. Users will also appreciate the option to connect a second display (Knomi) to the extruder front cover and an integrated temperature sensor for better control over the printing process.

For technically skilled users and professionals in 3D printing, this board represents an ideal choice thanks to its advanced features and reliability.

Main Technical Section

Key Features:

• Powerful MCU: The board is equipped with a 64 MHz STM32 MCU, ensuring reliable performance and higher data transfer rates.
• Silent Driver: TMC2209 driver provides quiet operation with diagnostic features such as short circuit protection, open circuit protection, and thermal shutdown.
• Easy Installation: Drop-in installation with carefully arranged connectors and integrated connections.

Expansion Options:

• Interface: USB Type-C for communication, expansion ports for probes, RGB lighting, I²C, endstops, and more.
• Sensor Support: Integrated LIS2DW sensor and support for temperature sensors such as 100K NTC or PT1000.

Technical Specifications

• MCU: RP2040 Dual ARM Cortex-M0+ at 133 MHz
• Input Voltage: DC12V-DC24V 9A
• Logic Voltage: DC 3.3V
• Connectors: PH2.0
• Driver Control Mode: UART
• Maximum Current for Fan Port: 1A continuous, 1.5A momentary
• Communication Interface: USB Type-C
• Expansion Ports: USB2.0 x 3, I²C, Endstop, IND or FAN, 5V OUT

GitHub Configuration

For detailed configuration of the BIGTREETECH EBB SB2209 USB board, you can visit the official GitHub repository. Here you will find sample configuration file structure and details about pin settings and other parameters needed to optimise your 3D printing process.

BIGTREETECH EBB SB2209 USB is an excellent choice for those seeking a robust and powerful solution for their Voron StealthBurner printers. With its advanced features and easy installation, it is an ideal product for technically skilled users and professionals in 3D printing.
